ACETex® PET
Geotextiles
ACETex® PET- Polyester woven geotextiles with high tensile strength at very low elongation
High strength woven geotextile with premium quality and excellent LTDS performance
Highly applicable to reinforcement structure
Easy handling and installation to reduce construction time and costs
During Construction
During Construction
During Construction
During Construction
About
High-Strength PET Woven Geotextiles for Soil Reinforcement
ACETex® PET are engineered woven geotextiles fabricated with high tenacity and high molecular weight polyester (PET) yarns. ACETex® PET geotextiles have high tensile strength at very low strain for soil reinforcement applications including soft soil stabilization, base reinforcement, embankments on soft soils and working platforms, etc.
Function
Separation
Reinforcement
Features
High tensile strength at very low elongation
The ultimate tensile strength of ACETex® PET geotextiles can reach over 1400kN/m in uniaxial direction as the main loading direction and up to 600kN/m x 600kN/m in bi-axial directions, and the strength is generated typically at very low strains. Furthermore, ACETex® PET geotextiles have excellent CBR value, demonstrating its outstanding ability to be a reinforcement component.
Outstanding Long-Term Design Strength (LTDS) proven by numerous tests from accredited laboratories
The polyester yarns used for producing ACETex® PET geotextiles have very high tenacity with premium quality, making ACETex® PET be able to provide excellent long-term design strength (LTDS) with excellent ability against installation damage, chemical degradation and creep for a 120-year design life.
Highly cost-effective for soil reinforcement applications
The usage of PET woven geotextiles in soil reinforcement applications has been proven a very cost-effective construction method, especially when both high-strength reinforcement and separation functions are needed. ACETex® PET geotextiles offer more advantages of easy construction and cost saving because its weight is lighter than most similar products. Besides, ACETex® PET geotextile series are available in various tensile strength to meet diverse project engineering needs, and the rolls are available in wide widths up to 5.2m to reduce the textile used for overlap.
With rigorous manufacturing and quality control processes, The ACETex® series products are ensured their high standard performance and recognized by customers around the world. The benefits of using ACETex® PET are summarized as below:
• Enhance structural stability with limited differential settlement
• High performance, quality and durability to ensure safety and cost efficiency
• Easy handling and installation to reduce construction time and costs
